Features of TOPPING DX3 PRO Desktop Bluetooth Decoding Amp AK4493 USB DAC

There're 4 output modes of DX3 Pro: Headphone amp only, Headphone amp + Line out, DAC only, Pre-amplifier which covers a wide range of use cases.


DX3 Pro is uses XMOS XU208 + 2 x AK4493 + OPA1612 to support up to 32bit768kHz PCM decoding and DSD512 native decoding for USB input.

AK4118 is an excellent receiver with low jitter and good compatibility. DX3 Pro has 2 x Coaxial and 1 x Optical input which support up to 24bit192kHz PCM decoding. DX3 Pro also has BlueTooth input which supports SBC, ACC, APTX, APTX-II, APTX-HD protocol.

DX3 Pro also comes with a great headphone amplifier. The output power is up to 1000mW x 2@32ohm load or 125mW x 2@300ohm and works for almost all headphones.

In addition, the output impedance of it is lower than 0.1 ohm by design.

dx3p-en-01dx3p-en-02dx3p-en-03dx3p-en-04dx3p-en-05dx3p-en-06dx3p-en-07dx3p-en-08dx3p-en-09dx3p-en-10dx3p-en-11dx3p-en-12dx3p-en-13dx3p-en-14dx3p-en-15dx3p-en-16dx3p-en-17dx3p-en-18dx3p-en-19



US / EUdx3p-en-20dx3p-en-21dx3p-en-22dx3p-en-23dx3p-en-24dx3p-en-25dx3p-en-26dx3p-en-27

Built-in 2*AK4493 chip,1*AK4118 chip.
Headphone amp output power: 1000mW*2@32Omega;125mW*2@300 Omega.
USB support: DSD64-DSD512(Native); DSD64-DSD256(DOP).
One year warranty.
USB IN :
44.1kHz-768kHz/16bit-32bit,
DSD64-DSD512(NATIVE)
DSD64-DSD256(DOP)
OPT/COAX IN : 44.1kHz-192kHz/16bit-24bit
BT IN : AAC/SBC/APTX/APTX-LL/APTX-HD.
Size:12*16.5*4cm
Weight:400g
DC power: DC15V/1A
Color: Black/Silver
Line out: RCA
HP output: 3.5mm
