Frequency Response Graphs: What They Reveal and What They Don't about an IEM

Frequency Response Graphs: What They Reveal and What They Don't about an IEM

What is a Frequency Response Graph?

A frequency response graph is a visual representation of how a pair of IEMs reproduces sound across the audible frequency range. The graph typically displays the amplitude (volume) of the sound at each frequency (how loud it is), with the frequency range being shown on the horizontal axis and the amplitude on the vertical axis. Understanding these graphs can give you valuable insights into the sound signature of the IEMs and help you make an informed decision when choosing a pair.



SeeAudio Rinko



What Can a Frequency Response Graph Tell us about an IEM?

Analyzing an In-Ear Monitor's (IEM) frequency response graph can reveal crucial details about its sound signature and performance. Here are key insights we can gather:

>Bass Response: The graph indicates the IEM's bass output. A higher curve in the low-frequency range suggests a bass-heavy sound, while a flatter response indicates a more balanced bass. For example, the Seeaudio Rinko IEM boasts an exceptional bass response, clearly evident from its frequency response graph.



AFUL Performer8



>Midrange: The midrange, where most vocals and instruments lie, is crucial. A smooth response here signifies accurate reproduction, while peaks or dips can affect clarity and warmth. The AFUL Performer 5 and Performer 8 IEMs are excellent examples of earphones known for their exceptional midrange reproduction.

>Treble Extension: The treble's presence and extension are visible in the graph's higher frequencies. A smooth, extended treble often implies better detail and airiness. An IEM with outstanding treble response, such as the NiceHCK Himalaya, is often detailed and revealing, highlighting nuances in the music with clarity.



NICEHCK Himalaya



>Sound Signature: The frequency response graph of an IEM can reveal its overall sound signature. For example, a V-shaped sound, with boosted bass and treble but recessed midrange, is shown by peaks in the bass and treble frequencies and a dip in the midrange.

>Soundstage and Imaging: While not directly shown, a balanced response across frequencies can suggest a wide soundstage and precise imaging.

>Harmonics and Resonances: Peaks and dips in the graph can reveal resonances or emphasis on specific harmonics, affecting tonal balance and timbre.

>Target Response Curve: Comparing the graph to the Harman curve for example can indicate if the IEM aligns with the preferred sound signature for most listeners. You could also compare the IEM’s frequency response graph to your favorite target curve allowing you to know if an IEM is likely to going to align with your preferences.  The Binary Chopin IEM serves as an excellent example of an earphone that aligns closely with the Harman Curve, a frequency response target curve derived from extensive research on preferred sound signatures.



Binary Chopin



>Dynamic Range: The graph's range from the lowest to the highest point can hint at the IEM's overall dynamic range and capability to reproduce subtle nuances.

Understanding these aspects from a frequency response graph can help you choose an IEM that aligns with your listening preferences and desired sound signature.

What the Frequency Response Graph Can’t Tell Us?

While frequency response graphs provide valuable insights into an In-Ear Monitor's (IEM) sound signature, there are several aspects of its performance and characteristics that cannot be fully determined from the graph alone:



AFUL Performer5



>Sound Quality: The graph provides a general overview of the frequency response, but it doesn't capture the subjective aspects of sound quality such as clarity, detail retrieval, and overall dynamics. Consider the AFUL Performer 5 and Performer 8. Despite their similar frequency response graphs, these IEMs differ significantly in price and sound quality, as well as detail retrieval.

>Transparency and Resolution: The ability of an IEM to reveal subtle details and textures in music, known as transparency and resolution, cannot be assessed solely from the frequency response graph.

>Soundstage and Imaging: While a balanced frequency response can suggest a wide soundstage, the graph doesn't provide information about the IEM's imaging capabilities or the placement of instruments within the soundstage. The graph also doesn’t say anything about the soundstage depth or spatial cues.

>Transient Response: The graph doesn't reveal how quickly the IEM can respond to rapid changes in sound, which can impact the overall dynamics and realism of the audio.



AFUL MagicOne



>Timbre and Naturalness: The graph cannot convey the timbre or naturalness of the sound, which is influenced by factors such as the quality of the drivers, materials used, and tuning choices made by the manufacturer.

>Comfort and Fit: The fit and comfort of an IEM, which can significantly impact the listening experience, cannot be determined from the frequency response graph. Nozzle diameter and the overall ear shell size are among several factors that influence the fit and comfort of an IEM.

>Isolation and External Noise: The graph doesn't provide information about the IEM's ability to isolate external noise, which is important in noisy environments or for critical listening.



Hiby ACE



>Driver Type: Although specific drivers may excel in reproducing particular frequencies, identifying the driver type solely from a frequency response graph is not possible. A single balanced armature (BA) IEM, such as the AFUL MagicOne, may have a frequency response graph similar to that of dynamic driver IEMs. However, the graph alone cannot determine the type of driver used in an IEM.

>Ease of driving: The ease of driving an IEM depends on its impedance and sensitivity. Sensitivity, measured in dB/mW, indicates how loud the IEM will be for a given power. It's essential to check the manufacturer's specifications for these details, as they are not shown in frequency response graphs. PhoenixCall is one example of an easy to drive IEM.

>Distortion: Distortion, which affects sound quality, isn't shown in frequency response graphs. It's important to check the manufacturer's specs for distortion figures, as lower values indicate a more faithful sound reproduction.



Celest Phoenixcall



While frequency response graphs are a valuable tool for understanding an IEM's sound signature, they are only one part of the picture and should be used in conjunction with other factors such as reviews, personal listening tests, and manufacturer specifications to get a complete picture of the IEM's performance and suitability for your preferences.
